Description
- Cylinder head measurement improved throughput by 690%.
- Measuring the valve seat and guide is one of the most challenging automotive metrology tasks.
- Using spiral scanning, the REVO® head collects thousands of data points that define seat height, diameter, width, and form.
- Throughput improved by up to 922%.
- Blade-integrated disks ("blisks") present extreme accessibility challenges and usually require multiple head indexes.
- Renishaw’s 5-axis technology greatly reduces cycle counts through continuous scanning of blade surfaces, edges, and root profiles.
- Incorporates Renscan5™ five-axis scanning to minimize CMM movement and dynamic errors.
- Measurement speed up to 500 mm/s increases throughput.
- Data capture rate up to 6000 points per second.
- Infinite positioning and five-axis motion minimize non-productive transitions.
- Stylus wear minimized by ultra-low scanning forces.
- Unlimited positioning improves access to complex geometries.
- Fast calibration with retained positions maximizes measurement time.
- Reach up to 500 mm while maintaining effective working length.
- Uses standard M2 styli for convenience.
- Probe and stylus interchangeability ensures flexibility and compatibility with future probing technologies.
